Polyscope
Four-channel oscilloscope module for Hector with its own full-screen UI, an LV2 capture plugin and a checksum-checked USB installer.
- Distribution
- Prebuilt image you flash yourself
- Requires stock
- 407
- oscilloscope
- utility
- ui
- lv2
- installer
Hector
Poly EffectsEurorack & modular
30 HP Eurorack module running the Beebo module-patching firmware
Hector is a 30 HP Eurorack module from Poly Effects with six audio and CV inputs, eight outputs and MIDI in and out. It runs the same touchscreen firmware as the Beebo pedal, which hosts a library of more than a hundred LV2 modules that are patched together on screen, including sequencers, convolution reverb, a looper, filters, LFOs and oscillator voices. Presets can be swapped with Beebo.
- Platform
- Debian-based Linux on a removable CPU module (Ingen plugin host, LV2 plugins, Qt/QML UI)
- Stock firmware
- 407
- Manufacturer
- polyeffects.com
- Community
- Related
Notes
Hector shares its firmware with the Beebo pedal, so the official UI source and the community Polyscope oscilloscope patch apply to the same code base. Updates are installed from a USB stick; read the install notes on each firmware entry before starting.
Firmware 2
Poly Effects Beebo/Hector firmware (digit_ui)
Official Poly Effects firmware for Beebo and Hector, whose Qt/QML touchscreen UI and Python glue code are published on GitHub.
ActiveSource: openunspecified- Distribution
- Prebuilt image you flash yourself
- Requires stock
- 338 (units already on 403-406 can use a smaller update package)
Brick risk. Flashing this carries a known, documented risk of damaging the device.
- official
- os
- ui
- modular
- fx
- lv2
Poly Effects Beebo/Hector firmware (digit_ui) version history Version Date Notes 407 (May 2026 installer) 2026-05-06 Installer that moves 407 to a self-healing file system; source commits through 2026-04-29. v407 2025-11-24 Git tag; no GitHub release page. v406 2025-11-01 Git tag; no GitHub release page. v404 2025-10-20 Git tag; no GitHub release page.
