Vink
Firmware for Workshop System Computer (Music Thing Modular)
Dual delay loops with sigmoid saturation for Jaap Vink / Roland Kayn style feedback patching.
by Ben Regnier
ActiveSource: openunspecified
- Distribution
- Prebuilt image you flash yourself
- Source
- github.com https://github.com/TomWhitwell/Workshop_Computer/tree/main/releases/32_vink
- Homepage
- computer.musicthing.co.uk https://computer.musicthing.co.uk/programs/32-vink/
- Synced from
- upstream metadata, raw.githubusercontent.com https://raw.githubusercontent.com/TomWhitwell/Workshop_Computer/main/releases/32_vink/info.yaml. Corrections belong upstream.
- delay
- feedback
- saturation
- dual-tap
- experimental
- cards
- draft
Description
Draft listing upstream (info.yaml draft: true). Vink provides two independently time-modulated delay taps with optional sigmoid saturation blend. Main controls base delay time, X controls tap 2 offset, and Y crossfades dry to saturated output. In switch up, outputs are split per tap; in middle/down, taps are mixed to mono on both outputs. CV In 1 and CV In 2 modulate tap times. Pulse outputs track tap periods.
Version history
| Version | Date | Notes |
|---|---|---|
| 1.1 | 2026-01-28 | Version and date from the card's info.yaml. |
